HPE FlexNetwork MSR Series Comware 5 Layer 2 - Wan Access Configuration Guide

94
Step Command Remarks
10. Configure a traffic class.
a. Create a traffic class and enter class
view:
traffic classifier tcl-name [ operator
{ and | or } ]
b. Configure the match criteria:
if-match [ not ] match-criteria
c. Exit class view:
quit
N/A
11. Configure a behavior with
the action of marking the
DE bit.
a. Create a behavior and enter behavior
view:
traffic behavior behavior-name
b. Configure the DE bit marking action:
remark fr-de fr-de-value
c. Exit behavior view:
quit
N/A
12. Configure a policy.
a. Create a policy and enter the policy
view:
qos policy policy-name
b. Associate the class with the traffic
behavior in the QoS policy:
classifier tcl-name behavior
behavior-name
c. Exit policy view:
quit
N/A
13. Apply the QoS policy to
an FR class.
a. Enter FR class view:
fr class class-name
b. Apply the QoS policy to the FR class:
apply policy policy-name outbound
c. Exit FR class view:
quit
N/A
14. Associate
the FR
class with
an FR
interface
or FR
PVC.
(Method 1)
Associate
the FR class
with an FR
interface
a. Enter FR interface view:
interface interface-type
interface-number
b. Associate the FR class with the FR
interface:
fr-class class-name
Use either method or
all.
By default, no FR
class is associated
with any FR
interfaces or FR
PVCs.
(Method 2)
Associate
the FR class
with an FR
PVC
c. Enter FR interface view:
interface interface-type
interface-number
d. Enter FR PVC view:
fr dlci dlci
e. Associate the FR class with the FR PVC:
fr-class class-name
For more information about configuring traffic classes, traffic behaviors, and QoS policies, see HPE
FlexNetwork MSR Router Series Comware 5 ACL and QoS Configuration Guide.
For more information about configuring FR classes, see HPE FlexNetwork MSR Router Series
Comware 5 ACL and QoS Configuration Guide.
Configuring frame relay fragmentation
The device supports the end-to-end FRF.12 fragmentation function.
