Configuring MPoFR
Multilink PPP over Frame Relay (MPoFR) enables Frame Relay stations to transmit MP fragments
between them.
To configure MPoFR:
• Configure at least two virtual templates for PPPoFR, without assigning IP addresses to them.
• Create a virtual template for MP and bind the PPPoFR virtual templates with this MP virtual
template.
To ensure transmission quality over virtual template interfaces, configure queue-independent QoS
features on the virtual interfaces and queue-dependent QoS features on the FR interface. For more
information, see HPE FlexNetwork MSR Router Series Comware 5 ACL and QoS Configuration
Guide.
When you configure a static route for a virtual-template interface, specify only the next hop. If you
want to specify the outbound interface as well, make sure the physical interface bound to the virtual
template interface is up.
For more information about MP configuration, see "Configuring PPP and MP."
Configuration procedure
To configure MPoFR:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create a virtual
template interface for
implementing MP.
interface virtual-template
interface-number-mp
N/A
3. Configure the
maximum bandwidth
for the interface.
qos max-bandwidth
bandwidth
Optional.
The default maximum bandwidth
of a virtual template interface is 64
kbps.
4. Assign an IP address
to the interface.
ip address
ip-address { mask-length |
mask }
N/A
5. Return to system view.
quit
N/A
6. Create a virtual
template for PPPoFR.
interface virtual-template
interface-number
N/A
7. Bind the PPPoFR
virtual template to the
MP virtual template.
ppp mp virtual-template
interface-number-mp
N/A
8. Return to system view.
quit
N/A
9. Enter frame relay
interface view.
interface
interface-type
interface-number
N/A
10. Enable frame relay on
the interface.
link-protocol fr
[
ietf
|
nonstandard
] N/A
11. Create a frame relay
DLCI.
fr dlci
dlci-number Optional on the DTE side.
12. Return to frame relay
interface view.
quit
N/A
