Step Command Remarks
4. Configure an IPoA mapping
for the PVC, and enable the
PVC to carry IP packets.
map ip
{ ip-address [ ip-mask ] |
default
|
inarp
[ minutes ] }
[
broadcast
]
By default, no mapping is
configured. If a mapping is
configured, pseudo-broadcast is
not supported by default.
Before configuring InARP, make
sure aal5snap encapsulation is
used. InARP is not supported
when aal5mux or aal5nlpid
encapsulations is adopted.
Configuring IPoEoA
When you configure IPoEoA, follow these guidelines:
• When multiple Layer 3 VE interfaces are connected through PVCs to a DHCP server that
assigns IP addresses to the interfaces through static address binding, configure different MAC
addresses for the interfaces by using the mac-address command.
• In an IPoEoA application, Class Based Queuing (CBQ) should be configured on PVCs.
• You can configure PVC mapping in PVC view. For information about the configuration, see HPE
FlexNetwork MSR Router Series Comware 5 MPLS Configuration Guide.
To configure IPoEoA on a PVC:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create a virtual Ethernet
(VE) interface.
interface virtual-ethernet
interface-number
Configure the IP address on a VE
interface. It is invalid to configure
the IP address on the ATM
interface.
3. Return to system view.
quit
N/A
4. Enter ATM interface view.
interface atm
{ interface-number
| interface-number.subnumber }
N/A
5. Enable packet padding on
the ATM interface.
eoapad enable
Optional.
6. Create a PVC and enter its
view.
pvc
{ pvc-name [ vpi/vci ] |
vpi/vci }
N/A
7. Configure an IPoEoA
mapping on the PVC.
map bridge virtual-ethernet
interface-number
N/A
Configuring PPPoA
When two routers are connected using DSL interfaces through a dial-up connection, configure them
as PPPoA server and client, respectively. The two are different in that: with the PPPoA server,
configure an address pool to allocate an IP address for the remote node; with the PPPoA client,
configure address negotiation to accept the IP address allocated by the server end. For more
information, see "Configuring PPP and MP."
When you configure a static route for a virtual-template interface, specify the next hop rather than the
outgoing interface. If you want to specify the outgoing interface, make sure the physical interface
bound to the virtual-template is valid to ensure correct transmission.
