HPE FlexNetwork MSR Series Comware 5 Layer 2 - Wan Access Configuration Guide

223
Protocols and standards
• RFC 1795, Data Link Switching: Switch-to-Switch Protocol AIW DLSw RIG: DLSw Closed
Pages, DLSw Standard Version 1.0
• RFC 2166, APPN Implementer's Workshop Closed Pages Document DLSw V2.0
Enhancements
Hardware compatibility with DLSw
DLSw is not available on the following routers:
• MSR1000.
• MSR30-11E.
• MSR30-11F.
Configuring DLSw in an Ethernet environment
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enable bridging.
bridge enable
N/A
3. Enable a bridge set.
bridge
bridge-set
enable
N/A
4. Enable DLSw.
dlsw enable
Optional.
Enabled by default.
5. Create a local DLSw peer.
See "
Creating DLSw peers
."
N/A
6. Map a bridge set to DLSw.
See "
Mapping a bridge set to
DLSw
."
N/A
7. Add an Ethernet interface to
the bridge set.
See "
Adding an Ethernet interface
to a bri
dge set
."
N/A
8. Set DLSw timers.
See "
Setting DLSw timers
."
Optional.
9. Configure LLC2 parameters.
See "
Configuring LLC2
parameters
."
Optional.
10. Configure the multicast
function of DLSw v2.0.
See "
Configuring the multicast
function
of DLSw v2.0
."
Optional.
11. Configure the maximal
attempts of sending an
explorer frame in DLSw v2.0.
See "
Configuring the maximum
number of DLS
w v2.0 explorer
retries
."
Optional.
12. Apply an ACL in DLSw so
DLSw handles only Ethernet
frames that match the ACL.
See "
Applying an ACL in DLSw
."
Optional.
13. Configure DLSw Ethernet
redundancy.
See "
Configuring DLSw Ethernet
redundanc
y
."
Optional.
14. Configure local reachable
MAC or SAP addresses.
See "
Configuring local reachable
M
AC or SAP addresses
."
Optional.
