Task Remarks
Configuring Annex G
Optional
Marking the DE bit
Optional
Configuring frame relay fragmentation
Optional
Enabling the trap function
Optional
You can configure an NNI interface in the same way a DCE interface is configured. For the
configuration procedure, see "Configuring DCE side frame relay."
If one endpoi
nt of a link is an NNI interface, the peer endpoint must also be an NNI interface.
Configuring DTE side frame relay
Configuring basic DTE side frame relay
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter the view of the
interface connecting to the
Frame Relay network.
interface
interface-type
interface-number
N/A
3. Enable frame relay on the
interface.
link-protocol fr
[
ietf
|
nonstandard
]
The default link layer protocol of a
WAN interface is PPP.
4. Set the frame relay interface
type to DTE.
fr
interface-type
dte
Optional.
The default setting is DTE.
5. Configure frame relay LMI
protocol type.
fr lmi type
{
ansi
|
nonstandard
|
q933a
|
bi-direction
}
Optional.
The default setting is
q933a
.
Support for the
bi-direction
keyword varies with device
models.
6. Configure DTE side N391.
fr lmi n391dte
n391-value
Optional.
The default setting is 6.
7. Configure DTE side N392.
fr lmi n392dte
n392-value
Optional.
The default setting is 3.
8. Configure DTE side N393.
fr
lmi n393dte
n393-value
Optional.
The default setting is 4.
9. Configure DTE side T391.
timer hold
seconds
Optional.
The default setting is 10 seconds.
Configuring frame relay address mappings
Configure frame relay address mappings in one of the following ways:
• Manually create static mappings between remote IP addresses and local DLCIs. Use this
method when the network topology is relatively stable and no new users are expected in a
certain period of time. Because static mappings do not change, the network connections are
stable, and attacks from unknown users are avoided.
