HPE FlexNetwork MSR Series Comware 5 Layer 2 - Wan Access Configuration Guide

291
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enable dynamic address
learning.
bridge
bridge-set
learning
Optional.
Enabled by default.
3. Configure a static bridge
table entry.
bridge
bridge-set
mac-address
mac-address {
deny
|
permit
}
[
dlsw
|
interface
interface-type
interface-number ]
Optional.
No static table entry is configured
by default.
4. Configure aging time of
dynamic bridge table entries.
bridge aging-time
seconds
Optional.
300 seconds by default.
Configuring bridge routing
Bridge routing provides a forwarding capability that combines bridging and routing. When data of a
given protocol is exchanged between bridge interfaces, bridging occurs; when data of a given
protocol is exchanged between a bridge set and a non-bridge-set network, the protocol can be
routed. Before the built-in routing and bridging functionalities are activated, all protocol data can only
be bridged. With the built-in routing and bridging functionalities activated, datagrams of the specified
protocol can be either bridged or routed, and switching between bridging and routing can be
implemented flexibly through configuration commands.
A bridge-template interface is a virtual route-selecting interface, on which various network layer
properties can be configured. By configuring a bridge-template interface, you can connect the bridge
set to a routed network. A bridge set can have only one bridge-template interface. The number of a
bridge-template interface is the number of the bridge set it represents.
By default, if a bridge set contains Ethernet interfaces, its bridge-template interface will use the MAC
address of a random Ethernet interface. If the bridge set contains no Ethernet interfaces, its
bridge-template interface will use the system default MAC address, of which the first 5 bytes depend
on the device model and the last byte is the number of the bridge set.
If bridge sets by the same bridge set number are enabled on two or more devices, and a
bridge-template interface is created for each of these bridge sets when no Ethernet interfaces have
been added into these bridge sets, these bridge-template interfaces will use exactly the same default
MAC address. This will cause MAC address conflict. To avoid this situation, configure different MAC
addresses for different bridge-template interfaces.
To configure bridge routing:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enable bridge routing.
bridge routing-enable
Disabled by default.
3. Configure routing or bridging
of a specific network layer
protocol on a bridge set.
• Configure routing:
bridge bridge-set routing
{ ip | ipx }
• Configure bridging:
bridge bridge-set bridging
{ ip | ipx | others }
Optional.
By default:
• Routing of all network layer
protocols is disabled.
• Bridging of all network layer
protocols is enabled.
4. Create a bridge-template
interface and enter
bridge-template interface
view.
interface bridge-template
bridge-set
No bridge-template interfaces
exist by default.
