Configuring Router B
1. Configure an IPv4 address for interface Ethernet 0/0:
a. Select Interface Setup > WAN Interface Setup from the navigation tree.
b. Click the icon for interface Ethernet 0/0 and then perform the configurations shown
in Figure 386.
c. Select
Manual for Connect Mode.
d. Enter IP address 10.1.3.1.
e. Select IP mask 24 (255.255.255.0).
f. Click Confirm.
Figure 386 Configuring interface Ethernet 0/0
2. Configure an IP address for interface Ethernet 0/1, the physical interface of the tunnel:
a. Click the icon for interface Ethernet 0/1 and then perform the configurations shown
in Figure 387.
b. Select Manual for Connect Mode.
c. Enter IP address 2.2.2.2.
d. Select IP mask 24 (255.255.255.0).
e. Click Confirm.
