Figure 416 Adding a resource group

3. Configure the resource group as describe in Table 176.

4. Click Apply.

Table 176 Configuration items

Item Description

Resource Group

Name

Enter a name for the resource group.

Selected Resources

Specify resources for the resource group.

Available Resources
