33
Table 14 Configuration items (in IPoA mode)
Item Description
WAN Interface
Select the ADSL/G.SHDSL interface to be configured.
Connect Mode: IPoA
Select the IPoA connect mode.
PVC
Specify the VPI/VCI value for PVC.
TCP-MSS Set the maximum TCP segment length of an interface.
MTU Set the MTU of an interface.
IP Address
Specify the IP address of the ADSL/G.SHDSL interface.
Subnet Mask
Select a subnet mask for the ADSL/G.SHDSL interface.
Map IP
Specify the peer destination IP address of the mapped PVC.
Table 15 Configuration items (in IPoEoA mode)
Item Description
WAN Interface
Select the ADSL/G.SHDSL interface to be configured.
Connect Mode: IPoEoA
Select the IPoEoA connect mode.
PVC
Specify the VPI/VCI value for PVC.
TCP-MSS Set the maximum TCP segment length of an interface.
MTU Set the MTU of an interface.
IP Address
Specify the IP address of the ADSL/G.SHDSL interface.
Subnet Mask
Select a subnet mask for the ADSL/G.SHDSL interface.
Table 16 Configuration items (in PPPoA mode)
Item Description
WAN Interface
Select the ADSL/G.SHDSL interface to be configured.
Connect Mode: PPPoA
Select the PPPoA connect mode.
PVC
Specify the VPI/VCI value for PVC.
User Name
Specify the user name for identity authentication.
Password
Displays whether a password has been specified for identity authentication.
An empty field indicates that no password is configured.
New Password Specify or modify the password for identity authentication.
TCP-MSS Set the maximum TCP segment length of an interface.
MTU Set the MTU of an interface.
Table 17 Configuration items (in PPPoEoA mode)
Item Description
WAN Interface
Select the ADSL/G.SHDSL interface to be configured.
Connect Mode:
PPPoEoA
Select the PPPoEoA connect mode.
PVC
Specify the VPI/VCI value for PVC.
