35
Item Description
MTU Set the MTU of an interface.
2. In CE1 mode
Figure 22 Setting CE1/PR1 interface parameters (in CE1 mode)
Table 19 Configuration items (in CE1 mode)
Item Description
WAN Interface
Select the CE1/PR1 interface to be configured.
Work Mode: CE1
Select the CE1 work mode.
Operation
Select one of the following operation actions:
• Create—Binds timeslots.
• Remove—Unbinds timeslots.
Serial
Select a number for the created Serial interface.
Timeslot-List
Specify the timeslots to be bound or unbound.
User Name
Specify the user name for identity authentication.
Password
Display whether a password has been specified for identity authentication.
An empty field indicates that no password is configured.
New Password Specify or modify the password for identity authentication.
TCP-MSS Set the maximum TCP segment length of an interface.
MTU Set the MTU of an interface.
