HPE FlexNetwork MSR Series User Manual

404
Figure 797 Network diagram
Configuration procedure
1. Configure Router A: See Configuring Router A.
2. Configure Router B:
# Configure the call node.
Select Voice Management > IVR Services > Advanced Settings from the navigation tree,
select the Configure Call Node tab, and click Add to access the following page.
Telephone A
50
Eth1/1
1.1.1.1/24
Router A Router B
100
Eth1/1
1.1.1.2/24
Telephone B2
Telephone B1
500
