5. Operation of MEC Related Controllers
283
No. Operation Screen Remarks
6 Touch the value field of
velocity. When the numeric
keypad is displayed, touch [5],
[0], and then [ENT] .
Touch [Menu] to return to the
position setting screen.
7 “50.00” is shown in the speed
field.
Touch [Menu] to return to the
position setting screen.
8 Touch the value field of
acceleration.
When the numeric keypad is
displayed, touch [0], [.], [3],
and then [ENT].
Touch [Menu] to return to the
position setting screen.
9 “0.30” is shown in the
acceleration field.
Touch [Menu] to return to the
position setting screen.
10 Touch the value field of
deceleration.
When the numeric keypad is
displayed, touch [0], [.], [3],
and then [ENT].
Touch [Menu] to return to the
position setting screen.
11 “0.30” is shown in the
deceleration field.
Touch [Menu] to return to the
position setting screen.
