Keysight N9915-90020 User’s Guide 239
SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)FUTURE
How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA
Mode (Option 233–Mixed Analyzers))
2. For this example, the X axis Antenna softkey menu has been selected:
a. Then press Edit Antenna to edit the existing X axial antenna factor’s
Frequency and Antenna Factor table values that are stored in the
FieldFox [:Internal]:\Antenna\ directory (Refer to
Figure
9-25
). Then you can edit the following:
—Description – edits the name of the current antenna settings
table
— Antenna Factor Unit – edits the units from dB /m electric
antenna factor to dB S/m for the magnetic antenna factors.
None is displayed, when no antenna is detected.
—Frequency
– edits the frequency value measured that
corresponds to a particular Antenna Factor.
— Antenna Factor – edits the Antenna Factor (amplitude) that
corresponds to a particular frequency.
Refer to next step for details on editing the antenna Settings
table.
b. Use the arrows, the rotary knob, or numeric keypad to select
the table cell value to be edited (i.e., the Frequency Interpolation
value is not editable). Then:
i. Press
Edit Antenna to edit your existing antenna factors or
press New to add a a new antenna’s factors or to write over
your existing antenna’s file (i.e., Overwrite existing Antenna
data?
is displayed above the table).
— Choose Yes to write over the existing antenna file.
— Choose
No to create a new antenna file (default
filename is Example).
ii. Press Add Row to create additional Frequency and Antenna
Factor values.
iii. Press
Delete/Clear
then choose one of these:
— Delete Row – when pressed this choice deletes the
currently selected row of Frequency and Antenna
Factors (i.e., you must press
Yes
to delete a row or No
to exit the current softkey menu).
— Clear All – when pressed this choice deletes all of the
currently selected rows of Frequency and Antenna
Factors (i.e., you must press
Yes to deleted the rows or
No to exit the current softkey menu).
—
Back – To exit to previous softkey menu.
iv. Press
Done
when finished editing to exit.
