5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
— Storage Device
2. Press Scale/Amptd then choose:
— Autoscale
—
Unit dBm
—
External Gain
—
External Gain
Step 6: Enable Data Logging and Playback the Results
Data Logging creates a record of your data with a timestamp and GPS stamp
(refer to
“GNSS (GPS+) and GPS” on page 795). GPS must be enabled for the
log results to include a GPS stamp or use Preferences to enable the timestamp.
Refer to
Chapter 31, “System Settings.”
Features
— Log files contain cell results for different component carriers (CCs)
including timestamps and/or distance stamps.
— Timestamps are included in log files with or without GPS.
— GPS must be enabled for log altitude results.
See also
“GNSS (GPS+) and GPS” on page 795.
—Data results can be logged
— Data results can be saved to a *.CSV, DREC (Option 360 only), or *.KML file.
Refer to
“” on page 453.
— User specifies how often results are stored.
— Time: Store results every “n” seconds
— Altitude: Store results every “n” meters. GPS must be enabled to
store results by altitude.
Procedure
1. Press
Trace 6 > Data Logging to view the Data Logging softkeys and set
the
Record Settings, Record Save/Recall, and Indoor Map Data Logging.
— Record (Outdoor Logging) or
—
Play (If you have previously stored data recordings.)
a. Outdoor Mapping only: To set the
Record Settings—choose:
Spectrum and Strip Chart information is not recorded. Only the Table and
Bar Chart data are saved. See
“How to Record a Data Log” on page 456.
