Keysight N9915-90020 User’s Guide 659
Channel Scanner (Option 312)
How to Set Up Channel Scanner
Outdoor Mapping Procedure
For Indoor Mapping and more on Outdoor Mapping, see also
Chapter 16
Mapping and “Option 352 Indoor Maps Setup Procedure” on page 491,
“Option 352 Outdoor Maps Setup Procedure” on page 495, and “Setting up
Data Logging” on page 503
. See also, Chapter 33, “File Management.”
1. Press Measure 1 or Trace 6 > Data Logging
2. Outdoor Mapping Only: Press
Record Settings then:
— Meas Interval OFF ON (default = OFF) - set to ON
—
Interval Type Time Distance (default = Time) - choose a setting
— Time Interval 1 sec to 3,600 seconds or
—
Distance Interval from 1m to 10 km
— When done, press
Back
3. Press
Record Save/Recall then:
— Recall Log File
—
File Folder Default System - (default = Default).
—
File Type - CSV or KLM
—
Auto Save OFF ON - (default = OFF). Press to enable/disable.
— then
Back
Learn more, see “How to Set Up Channel Scanner” on page 647, step b.
4. To begin outdoor logging recording: Press
Record
If Auto Save is On (default = OFF) Measurements are stored automatically
accorded to the specified time or distance interval values. Refer to step
5.
5. Optional: Auto Save OFF (default)—When Auto Save is on, during
recording, the FieldFox stores intermediate results in a temporary file. If
the power fails during recording you can retrieve the results. Select
Recall
Log File. Select the temporary file name.
Press
Record Save/Recall > Auto Save On Off
6. When done press Stop or Esc. The files save dialog is displayed. Edit the
file name where the file results will be stored.
7. Press Done
Learn more, refer to Chapter 16 Mapping and “Option 352 Outdoor Maps
Setup Procedure” on page 495
and “Setting up Data Logging” on page 503.
See also,
Chapter 33, “File Management.”
