660 Keysight N9915-90020 User’s Guide
Channel Scanner (Option 312)
How to Set Up Channel Scanner
Playing a Data Log and Viewing the Spectrogram
To play the log results:
Refer to
Figure 28-13 on page 661.
1. Press Data Logging > Play
2. Then choose:
— Optional: Use the RPG (fine adjust) or the arrow keys (coarse adjust)
to change the color bar.
See also, “How to Set Up Channel Scanner” on page 647.
3. Press
Stop or Esc to exit the log recording.
To pause the log play:
1. Optional: Press Pause Resume to pause or resume the log recording.
2. Then choose:
— Optional: Use the RPG (fine adjust) or the arrow keys (coarse adjust)
to change the color bar.
— Cursor Position to change the position along the time
record’s results (i.e., Cursor Position is active only when
playback is paused).
—
Maps > Red/Blue Limits then
——Red Limit to change the color bar.
——
Blue Limit to change the color bar.
3. Press
Stop or Esc to stop the log recording.
To View the spectrogram of recorded results:
1. Press View (Applies to Option 312 Only)
2. Then choose:
—
Zoom to zoom in on spectrogram time record results.
—
Red Limit to change the color bar.
—
Blue Limit to change the color bar.
3. Press
Exit or Esc to exit view.
