Sampling mode
324
8–1c: OSC MFX Send
Send1 (to MFX1) [000...127]
Send2 (to MFX1) [000...127]
This sets the send levels at which the output of the oscillator
(multisample) is sent to the master effects. The master effects
are sent to the L/R bus. Set the Source Bus to L/R if you
want to use master effects while resampling.
You can use CC#93 to control the Send1 level and
CC#91 to control the Send2 level. The global MIDI
channel specified by MIDI Channel (Global 1–1a) is
used for these messages.
▼8–1: Menu Command
• 0: Panel–SW Solo Mode On ☞p.329
• 1: Exclusive Solo ☞p.329
• 2: Copy Insert Effect ☞p.352
• 3: Swap Insert Effect ☞p.352
For more information, please see “Sampling: Menu
Command” on page 329.
8–2: Insert FX Setup
In this page you can select the effect types for the insert
effects, turn them on/off, and make chaining settings.
8–2a: IFX
Here you can choose the type of each insert effect 1 through
5, its on/off status, chaining, and adjust the post-IFX mixer
settings. For insert effects, the direct sound (Dry) is always
stereo-in and out. The input/output configuration of the
effect sound (Wet) depends on the effect type.
For detailed explanations of the individual effects, please
see the “Insert Effects (IFX1…IFX5)” on page 426.
The following parameters are the same as in Program mode.
For more information, please see “8–2a: Insert Effect” on
page 99.
Insert Effect:
IFX1...4 [000...170]
IFX5 [000...153]
IFX1...5: IFX On/Off [Off, On]
Chain:
IFX1: Chain to [IFX2...IFX5]
IFX2: Chain to [IFX3...IFX5]
IFX3: Chain to [IFX4...IFX5]
IFX1: Chain [Off, On]
IFX2: Chain [Off, On]
IFX3: Chain [Off, On]
IFX4: Chain [Off, On]
Pan: #8 (Post IFX PanCC#8) [L000...C064...R127]
Bus(Bus Select) [L/R, 1...4, 1/2, 3/4, Off]
AUX/Ctrl:
AUX (AUX Bus) [Off, 1, 2, 3, 4, 1/2, 3/4]
Ctrl (FX Control Bus) [Off, 1, 2]
Send 1/2:
Send1 [000...127]
Send2 [000...127]
For more information, please see “8–2: Insert FX Setup” on
page 99.
8–2a
8–2
