Korg M3 Parameter Guide

Effect Guide
504
Mono/Mono Parallel (Mono//Mono)
109: P4EQ // P4EQ (Parametric 4-Band EQ // Parametric 4-
Band EQ) through 153: BPM Dl // BPM Dl (Multitap BPM
Delay // Multitap BPM Delay) are parallel effects.
The pan and effect balance of each effect can be set
independently.
In the screen, the L-side is shown as [1], and the R-side as
[2].
These provide various combinations of 4-band EQ,
Compressor, Limiter, Exciter, Overdrive, Wah, Chorus/
Flanger, Phaser, and Multitap Delay., as described below.
P4EQ (4-band EQ)
Comp (Compressor)
Limiter
Exciter
0D/HG (Overdrive)
P4EQ
aTrim 0...100 Sets the input level
b
B1 Cutoff
[Hz]
20...1.00k
Sets the center frequency of
Band 1
Q 0.5...10.0
Sets the bandwidth of Band 1
p.445
Gain [dB] –18.0...+18.0 Sets the gain of Band 1
c
B2 Cutoff
[Hz]
50...5.00k
Sets the center frequency of
Band 2
Q 0.5...10.0
Sets the bandwidth of Band 2
p.445
Gain [dB] –18.0...+18.0 Sets the gain of Band 2
d
B3 Cutoff
[Hz]
300...10.00k
Sets the center frequency of
Band 3
Q 0.5...10.0
Sets the bandwidth of Band3
p.445
Gain [dB] –18.0...+18.0 Sets the gain of Band 3
e
B4 Cutoff
[Hz]
500...20.00k
Sets the center frequency of
Band 4
Q 0.5...10.0
Sets the bandwidth of Band 4
p.445
Gain [dB] –18.0...+18.0 Sets the gain of Band 4
f
L Wet/Dry
(R Wet/Dry)
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
gL Pan (R Pan)
L000...C064...
R127
Sets the stereo image
COMPRESSOR
aSensitivity 1...100 Sets the sensitivity p.441
bAttack 1...100 Sets the attack level p.441
c Output Level 0...100 Sets the output level
d EQ Trim 0...100 Sets the EQ input level
e
Pre LEQ Gain
[dB]
–15...+15 Sets the gain of Low EQ
Pre HEQ Gain
[dB]
–15...+15 Sets the gain of High EQ
f
L Wet/Dry
(R Wet/Dry)
Dry,1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
gL Pan (R Pan)
L000...C064...
R127
Sets the stereo image
LIMITER
aRatio
1.0 : 1...
50.0 : 1, Inf : 1
Sets the signal compression
ratio p.494
b
Threshold
[dB]
–40...0
Sets the level above which the
compressor is applied p.494
cAttack 1...100 Sets the attack time
dRelease 1...100 Sets the release time
e
Gain Adjust
[dB]
–Inf,
–38...+24
Sets the output gain p.494
f
L Wet/Dry
(R Wet/Dry)
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
gL Pan (R Pan)
L000...
C064...R127
Sets the stereo image
EXCITER
aExciter Blend –100...+100
Sets the intensity (depth) of the
Exciter effect p.446
b
Emphasis
Point
0...70
Sets the frequency range to be
emphasized p.446
cTrim 0...100 Sets the EQ input level
d
Pre LEQ Gain
[dB]
–15...+15 Sets the gain of Low EQ
e
Pre HEQ Gain
[dB]
–15...+15 Sets the gain of High EQ
f
L Wet/Dry
(R Wet/Dry)
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
gL Pan (R Pan)
L000...C064...
R127
Sets the stereo image
OD/HI GAIN
a
Drive Mode
Overdrive,
Hi-Gain
Switches between overdrive
and high-gain distortion
Drive 1...100
Sets the degree of distortion
p.453
b
Output Level 0...50 Sets the output level p.453
Src Off...Tempo
Selects the modulation source
for the output level
Amt –50...+50
Sets the modulation amount of
the output level
c
Low Cutoff
[Hz]
20...1.00k
Sets the center frequency for
Low EQ (shelving type)
Gain [dB] –18...+18 Sets the gain of Low EQ
d
Mid1 Cutoff
[Hz]
300...10.00k
Sets the center frequency for
Mid/High EQ 1 (peaking type)
Q 0.5...10.0
Sets the band width of Mid/
High EQ 1 p.445
Gain [dB] –18...+18 Sets the gain of Mid/High EQ 1
e
Mid2 Cutoff
[Hz]
500...20.00k
Sets the center frequency for
Mid/High EQ 2 (peaking type)
Q 0.5...10.0
Sets the band width of Mid/
High EQ 2 p.445
Gain [dB] –18...+18 Sets the gain of Mid/High EQ 2
f
L Wet/Dry
(R Wet/Dry)
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
gL Pan (R Pan)
L000...C064...
R127
Sets the stereo image

Korg M3 Specifications

General

Synthesis Type	EDS (Enhanced Definition Synthesis)
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61-key, velocity-sensitive, aftertouch
Sequencer	16-track MIDI sequencer
Sampling	Open Sampling System
Display	TouchView graphical user interface with 320x240 color TFT LCD
Arpeggiator	2 polyphonic arpeggiators
Controllers	Joystick, Ribbon Controller
Outputs	L/MONO, R, Individual 1-4, Headphones
USB	Yes, USB MIDI
Storage	SD card slot
Combinations	1, 792 user combinations
Polyphony	120 voices (max)
Effects	5 Insert effects, 2 Master effects, 1 Total effect
