Effect Guide
464
037: St. Env. Phaser
(Stereo Envelope Phaser)
This stereo phaser uses an envelope generator for
modulation. You will obtain the same pattern of phasing
each time you play. You can also control the Phaser directly
using the modulation source.
i
Resonance –100...+100
Sets the resonance amount
p.463
High Damp
[%]
0...100
Sets the resonance damping
amount in the high range
p.463
j
Wet/Dry
–Wet...
–1 : 99, Dry,
1 : 99...Wet
Sets the balance between the
effect and the dry input
p.450, p.463
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
a
L Manu
Bottom
0...100
Sets the lower limit of the
frequency range for the effect
on the left channel
L Manu Top 0...100
Sets the upper limit of the
frequency range for the effect
on the left channel
b
R Manu
Bottom
0...100
Sets the lower limit of the
frequency range for the effect
on the right channel
R Manu Top 0...100
Sets the upper limit of the
frequency range for the effect
on the right channel
c
Sweep Mode EG, D-mod
Determines whether the
flanger is controlled by the
envelope generator or by the
modulation source p.462
Src Off...Tempo
Selects the modulation source
that triggers the EG (when EG is
selected for Sweep Mode), or
modulation source that causes
the flanger to sweep (when D-
mod is selected for Sweep
Mode) p.462
d
EG Attack 1...100
Sets the EG attack speed
p.462
EG Decay 1...100
Sets the EG decay speed
p.462
eResonance –100...+100
Sets the resonance amount
p.463
f
High Damp
[%]
0...100
Sets the resonance damping
amount in the high range
p.463
g
Wet/Dry
–Wet...
–1 : 99, Dry,
1 : 99...Wet
Sets the balance between the
effect and the dry input
p.450, p.463
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
EG Attack/Decay
EG
D-mod
Sweep Mode
D
-mod
Phaser
Phaser
Left
Right
Resonance
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
