Effect Guide
452
016: Stereo Decimator
This effect creates a rough sound like a cheap sampler by
lowering the sampling frequency and data bit length. You
can also simulate noise unique to a sampler (aliasing).
a: Pre LPF
If a sampler with a very low sampling frequency receives
very high-pitched sound that could not be heard during
playback, it could generate pitch noise that is unrelated to
the original sound. Set Pre LPF to On to prevent this noise
from being generated.
If you set the Sampling Freq to about 3 kHz and set Pre LPF
to Off, you can create a sound like a ring modulator.
g: Resolution
h: Output Level
If you set a smaller value for the Resolution parameter, the
sound may be distorted. The volume level may also be
changed. Use Output Level to adjust the level.
017: St. Analog Record
(Stereo Analog Record)
This effect simulates the noise caused by scratches and dust
on analog records. It also reproduces some of the
modulation caused by a warped turntable.
b: Flutter
This parameter enables you to set the depth of the
modulation caused by a warped turntable.
e: Click Level
This parameter enables you to set the level of the click noise
that occurs once every rotation of the turntable. This
simulation reproduces record noise, and the noise generated
after the music on a vinyl record finishes.
a
Pre LPF Off, On
Selects whether the harmonic
noise caused by a decrease in
sampling frequency is
generated or not p.452
High Damp
[%]
0...100
Sets the ratio of cut of the high
range
b
Sampling
Freq [Hz]
1.00k...
48.00k
Sets the sampling frequency
Src Off...Tempo
Selects the modulation source
of the sampling frequency
Amt
–48.00k...
+48.00k
Sets the modulation amount of
the sampling frequency
c
LFO
Frequency
[Hz]
0.02...20.00 Sets the speed of the LFO
Src Off...Tempo
Selects a modulation source for
LFO speed
Amt
–20.00...
+20.00
Sets the modulation amount of
LFO speed
d
MIDI Sync Off, On
When this is on, the LFO speed
is set by BPM, Base Note, and
Times, instead of Frequency
BPM
MIDI,
40.00...
300.00
MIDI syncs to the system
tempo; 40–300 sets the tempo
manually for this individual
effect
Base Note ...
Selects the type of notes that
specify the LFO speed
Times x1...x32
Sets the number of notes that
specify the LFO speed
e
LFO Type
Individual,
Common1,
Common2
Selects either (individual) LFO,
Common FX LFO1, or Common
LFO2 p.448
CmnLFO
Offset [deg]
–180...+180
Sets the phase offset when
Type = Common 1 or Common
2p.448
f
Depth 0...100
Sets the depth of the sampling
frequency LFO modulation
Src Off...Tempo
Selects the LFO modulation
source of the sampling
frequency
Amt –100...+100
Sets the LFO modulation
amount of the sampling
frequency
gResolution 4...24 Sets the data bit length p.452
h
Output Level 0...100 Sets the output level p.452
Src Off...Tempo
Selects the modulation source
for the output level
Amt –100...+100
Sets the modulation amount of
the output level
i
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Pre LPF
Pre LPF
High Damp Output Level
High Damp Output Level
Sampling Frequency
Decimator
Decimator
D
-mod
LFO
Resolution
Resolution
aSpeed [RPM]
33 1/3, 45, 78
Sets the r.p.m. of a record
bFlutter 0...100
Sets the modulation depth
p.452
c
Noise Density
0...100 Sets the noise density
Noise Tone 0...100 Sets the noise tone
d
Noise Level 0...100 Sets the noise level
Src Off...Tempo
Selects the modulation source
for the noise level
Amt –100...+100
Sets the modulation amount of
the noise level
e
Click Level 0...100
Sets the click noise level
p.452
Src Off...Tempo
Selects the modulation source
for the click noise level
Amt –100...+100
Sets the modulation amount of
the click noise level
f EQ Trim 0...100 Sets the EQ input level
g
Pre EQ Cutoff
[Hz]
300...10.00k Sets the EQ center frequency
Q 0.5...10.0 Sets the EQ band width
Gain [dB] –18.0...+18.0 Sets the EQ gain
h
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Analog Record
Simulation
Pre EQ
Pre EQ
EQ Trim
EQ Trim
