Effect Guide
484
j: Time Over? L, R
You can set the delay time up to 2,550msec. If the delay time
exceeds this limit, the error message “OVER!” appears in the
display. Set the delay time parameters so that this message
will not appear. Time Over? is only a display parameter.
068: St.BPMAutoPanDly
(Stereo BPM Auto Panning Delay)
This stereo auto panning delay enables you to set the delay
time to match the song tempo.
k
L Delay Base
Note
...
Selects the type of notes to
specify the left channel delay
time p.473
Times x1...x32
Sets the number of notes to
specify the left channel delay
time p.473
Feedback –100...+100
Sets the feedback amount of
left delay
l
R Delay Base
Note
...
Selects the type of notes to
specify the right channel delay
time p.473
Times x1...x32
Sets the number of notes to
specify the right channel delay
time p.473
Feedback –100...+100
Sets the feedback amount of
right delay
m
Wet/Dry
–Wet...
–1 : 99, Dry,
1 : 99...Wet
Sets the balance between the
effect and the dry input
p.450
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
a
BPM
MIDI,
40.00...
300.00
MIDI syncs to the system
tempo; 40–300 sets the tempo
manually for this individual
effect p.473
Time Over? L ---, OVER!
Display the error message if the
left channel delay time exceeds
the upper limit p.482
R ---, OVER!
Display the error message if the
right channel delay time
exceeds the upper limit p.482
b
L Delay Base
Note
...
Selects the type of notes to
specify the left channel delay
time p.473
Times x1...x32
Sets the number of notes to
specify the left channel delay
time p.473
Feedback –100...+100
Sets the feedback amount for
the left channel
c
R Delay Base
Note
...
Selects the type of notes to
specify the right channel delay
time p.473
Times x1...x32
Sets the number of notes to
specify the right channel delay
time p.473
Feedback –100...+100
Sets the feedback amount for
the right channel
d
High Damp
[%]
0...100
Sets the damping amount in
the high range p.476
Low Damp
[%]
0...100
Sets the damping amount in
the low range p.476
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO Phase
LFO Shape
Pan
Pan
LFO: Tri / Sin
Depth
Delay
Delay
High Damp Low Damp
High Damp
Low Damp
Feedback
e
LFO
Waveform
Triangle,
Sine
Selects the LFO Waveform
Shape –100...+100
Changes the curvature of the
LFO Waveform p.449
LFO Phase –180...+180
Sets the LFO phase difference
between the left and right
p.469
f
Panning Freq
[Hz]
0.02...20.00 Sets the panning speed p.448
g
MIDI Sync Off, On
When this is on, the pan LFO
speed is set by BPM, Base Note,
and Times, instead of
Frequency p.448
BPM
MIDI,
40.00...
300.00
MIDI syncs to the system
tempo; 40–300 sets the tempo
manually for this individual
effect p.448
Base Note ...
Selects the type of notes to
specify the delay time for the
panning speed p.448
Times x1...x32
Sets the number of notes to
specify the delay time for the
panning speed p.448
h
LFO Type
Individual,
Common1,
Common2
Selects either (individual) LFO,
Common FX LFO1, or Common
LFO2 p.448
CmnLFO
Offset [deg]
–180...+180
Sets the phase offset when
Type = Common 1 or Common
2p.448
i
Panning
Depth
0...100 Sets the panning width
Src Off...Tempo
Selects the modulation source
for the panning width
Amt –100...+100
Set the modulation amount of
the panning width
j
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
