Delay
485
069: Tape Echo BPM
This is a tape echo that lets you synchronize the delay time
to the tempo of the song.
a: Tap1 Dmod Src
b: Tap1 Delay Note
b: Times
c: Tap1 Dmod Note
c: Times
If Tap1 Dmod Src is Off or the selected modulation is at 0,
the delay time will be the length specified by Tap1 Delay
Note and Times.
If Tap1 Dmod Src is other than Off, the delay time will
change so that it will be as specified by Tap1 Dmod Note
and Times when the maximum modulation is reached.
b: Time Over?
You can set the delay time up to 5,400msec. If the delay time
exceeds this limit, the error message “OVER!” appears in the
display. Set the delay time parameters so that this message
will not appear. Time Over? is only a display parameter.
a
BPM (Delay)
MIDI,
40.00...
300.00
MIDI syncs to the system
tempo; 40–300 sets the tempo
manually for this individual
effect p.473
Tap1 Dmod
Src
Off...Tempo
Selects the modulation source
of the delay time p.485
b
Tap1 Delay
Note
...
Selects the type of notes to
specify the delay time (tap1)
p.473, p.485
Times x1...x32
Sets the number of notes to
specify the delay time (tap1)
p.473, p.485
Time Over? ---, OVER!
Displays an error message
when the delay time exceeds
the upper limit p.485
c
Tap1 Dmod
Note
...
Selects the note value used to
specify the delay time when the
modulation is at maximum
p.485
Times x1...x32
Specifies the number of notes
used to specify the delay time
when the modulation is at
maximum p.485
d
Tap2
Position [%]
0...100
Sets the position of Tap 2
relative to the Tap 1 delay time
the depth of pitch variation
p.480
e
Tap3
Position [%]
0...100
Sets the position of Tap 3
relative to the Tap 1 delay time
the depth of pitch variation
p.480
f
Tap1 Level 0...100 Sets the Tap1 output level
PanL, 1...99, R Sets the stereo image of tap1
FB Amt –100...+100
Sets the Tap1 feedback amount
p.480
g
Tap2 Level 0...100 Sets the Tap2 output level
PanL, 1...99, R Sets the stereo image of tap2
FB Amt –100...+100
Sets the Tap2 feedback amount
p.480
h
Tap3 Level 0...100 Sets the Tap3 output level
PanL, 1...99, R Sets the stereo image of tap3
FB Amt –100...+100
Sets the Tap3 feedback amount
p.480
i
Feedback 0...100
Sets the amount of feedback
for Taps 1, 2, and 3 p.480
Src Off...Tempo
Selects the modulation source
of feedback amount
Amt –100...+100
Sets the depth by which
feedback amount will be
modulated
j
High Damp
[%]
0...100
Sets the damping amount in
the high range
Low Damp
[%]
0...100
Sets the damping amount in
the low range
kSaturation 0...100 Sets the distortion amount
l
Input Trim 0...100 Sets the input gain
Pre Tone 0...100 Sets the tone of the input
m
Wow Flutter
[Hz]
0.02...1.00
Sets the frequency at which
pitch variation will occur
Wow Flutter
depth
0...100
Sets the depth of pitch
variation
Wah Flatter
D
-mod
Tap2/3 Position
+
Tape
Saturation
Left
Right
Wet / Dry
Trim
PanLevel
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
Feedback
Feedback Amt
High / Low DampPre Tone
Delay
(1)
(2)
(3)
Delay Time
BPM
BPM
Base Note x Times
Tempo
n
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
