Global mode
358
• 5: Half Damper Calibration ☞p.383
• 6: Pad Calibration ☞p.383
• 7: After Touch Calibration ☞p.383
• 8: Update System Software ☞p.384
For more information, please see “Global: Menu Command”
on page 382.
0–2: System Preference
Here you can make overall settings for the entire system
such as bank map, system clock, and memory protect.
0–2a: System Preference
Bank Map [KORG, GM(2)]
This specifies the mapping of programs and combinations
relative to Bank Select control change messages (CC#0
upper byte and CC#32 lower byte).
The bank select messages shown in the table below will be
received (R) and transmitted (T) for Program banks INT–A –
F, G, g(1)…g(9), g(d), USER-A–G and Combination banks
INT-A–G, and USER-A–G.
The bank types are as follows.
To specify the type for banks USER-A–G, use the menu
command Set Prog User-Bank Type.
Be aware that in Media mode if you load data of a
differing bank type from a PCG file into USER-A–G
bank, the existing data will be overwritten.
When MIDI System Exclusive messages or program
data dumps are received, only data of the same bank
type is received. Data of a differing bank type will not
Bank Bank Map: KORG Map: GM(2)
INT–A 00. 00 R/T 63. 00 R/T
INT–B 00. 01 R/T 63. 01 R/T
INT–C 00. 02 R/T 63. 02 R/T
INT–D 00. 03 R/T 63. 03 R/T
INT–E 00. 04 R/T 63. 04 R/T
INT–F 00. 05 R/T 63. 05 R/T
INT–G, 121. 00 R/T, 56. 00 R 121. 00 R/T, 56. 00 R, 00. 00 R
g(1)...g(9) 121. 01...09 R/T 121. 01...09 R/T
g(d) 120. 00 R/T, 62. 00 R 120. 00 R/T, 62. 00 R
USER–A 00. 08 R/T 63. 08 R/T
USER–B 00. 09 R/T 63. 09 R/T
USER–C 00. 10 R/T 63. 10 R/T
USER–D 00. 11 R/T 63. 11 R/T
USER–E 00. 12 R/T 63. 12 R/T
USER–F 00. 13 R/T 63. 13 R/T
USER–G 00. 14 R/T 63. 14 R/T
Bank Bank Type
INT–A…INT–E Banks for EDS only
INT–F Bank for EXB-RADIAS only
INT–G,
g(1)…g(9), g(d)
GM2 program banks (EDS)
G: GM2 capital programs
g(1)…g(9): GM2 variation programs
g(d): GM2 drum programs
USER–A…G
Banks selectable for either EDS or EXB-RADIAS
(default is EDS)
0–2a
0–2b
0–2
