Effect Guide
514
Double Size
Double-size effects can be used only with insert effects IFX1,
2, 3, 4 and master effect MFX1.
154: St. Mltband Limiter
(Stereo Multiband Limiter)
This is a stereo multiband limiter.
155: PianoBody/Damper
(PianoBody/Damper Simulation)
This effect simulates the resonance of the piano sound board
caused by the string vibration, and also simulates the
resonance of other strings that are not being played when
you press the damper pedal. It will create a very realistic
sound when applied to acoustic piano sounds.
a: Sound Board Depth
This parameter sets the intensity of resonance of the piano
sound board.
b: Damper Depth
b: Src
This parameter sets the resonance intensity of the other
strings created when the damper pedal is pressed. The Src
parameter selects the modulation source from which the
damper effect is applied. Usually, select Damper #64 Pdl
(Damper pedal).
The effect is off when a value for the modulation source
specified for the Src parameter is 63 or smaller, and the
effect is on when the value is 64 or higher.
c: Tone
d: Mid Shape
These parameters control the tonal quality of the effect
sound.
e: Tune
Since this effect simulates the resonance of the strings, the
sound varies depending on the pitch. If you have changed
tuning using the Master Tune (Global P0), adjust this
parameter value.
aRatio
1.0 : 1...
50.0 : 1, Inf : 1
Sets the signal compression
ratio p.494
b
Threshold
[dB]
–40...0
Sets the level above which the
compressor is applied p.494
cAttack 1...100 Sets the attack time
dRelease 1...100 Sets the release time
e
Low Offset
[dB]
–40...0
Sets the low range gain of
trigger signal p.443
f
Mid Offset
[dB]
–40...0
Sets the mid range gain of
trigger signal p.443
g
High Offset
[dB]
–40...0
Sets the high range gain of
trigger signal p.443
h
Gain Adjust
[dB]
–Inf,
–38...+24
Sets the output gain p.494
Src Off...Tempo
Selects the modulation source
for the output gain
Amt –63...+63
Sets the modulation amount of
the output gain
i
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Gain Adjust
Limiter
Limiter
Limiter
Envelope - Control
Envelope - Control
Envelope - Control
Gain Adjust
Limiter
Limiter
Low
Mid
High
Envelope - Control
Envelope - Control
Envelope - Control
Low
Mid
High
Offset
Band-Pass Filters
Limiter
a
Sound Board
Depth
0...100
Sets the intensity of resonance
of the sound board p.514
b
Damper
Depth
0...100
Sets the intensity of the string
resonance created when the
damper pedal is pressed p.514
Src Off...Tempo
Selects the modulation source
of damper effect p.514
cTone 1...100
Sets tonal quality of effect
sound p.514
dMid Shape 0...36
Sets the mid range of tonal
quality p.514
eTune –50...+50 Fine tuning p.514
f
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
D
-mod
Piano
Body/Damper
Simulation
Damper
+
