Modulation and Pitch Shift (Mod./P.Shift)
473
050: Pitch Shifter
This effect changes the pitch of the input signal. You can
select from three types: Fast (quick response), Medium, and
Slow (preserves tonal quality). You can also create an effect
in which the pitch is gradually raised (or dropped) using the
delay with feedback.
a: Mode
This parameter switches the pitch shifter operating mode.
With Slow, tonal quality will not be changed too much. With
Fast, the effect becomes a Pitch Shifter that has a quick
response, but may change the tone. Medium is in-between
these two. If you do not need to set too much pitch shift
amount, set this parameter to Slow. If you wish to change
the pitch significantly, use Fast.
b: Pitch Shift [1/2tone]
b: Src
b: Amt
c: Fine [cents]
c: Amt
The amount of pitch shift will use the value of the Pitch
Shift plus the Fine value. The amount of modulation will
use the b: Amt value plus the c: Amt.
The same Modulation Source is used for both Pitch Shift
and Fine.
e: Feedback Position
f: Feedback
When Feedback Position is set to Pre, the pitch shifter
output is again input to the pitch shifter. Therefore, if you
specify a higher value for the Feedback parameter, the pitch
will be raised (or lowered) more and more each time
feedback is repeated.
If Feedback Position is set to Post, the feedback signal will
not pass through the pitch shifter again. Even if you specify
a higher value for the Feedback parameter, the pitch-shifted
sound will be repeated at the same pitch.
051: Pitch Shifter BPM
This pitch shifter enables you to set the delay time to match
the song tempo.
d: BPM
e: Delay Base Note
e: Times
The delay time is the duration of Times number of Delay
Base Note note values at the BPM tempo (or if BPM is set to
MIDI, the tempo determined by MIDI Clock).
d: Time Over?
You can set the delay time up to 5,290msec. If the delay time
exceeds this limit, the error message “OVER!” appears on
the display. Set the delay time parameters so that this
aMode
Slow,
Medium,
Fast
Switches Pitch Shifter mode
p.473
b
Pitch Shift
[1/2tone]
–24...+24
Sets the pitch shift amount by
steps of a semitone p.473
Src Off...Tempo
Selects the modulation source
of pitch shift amount p.473
Amt –24...+24
Sets the modulation amount of
pitch shift amount p.473
c
Fine [cents] –100...+100
Sets the pitch shift amount by
steps of a cent p.473
Amt –100...+100
Sets the modulation amount of
pitch shift amount p.473
d
Delay Time
[msec]
0...2000 Sets the delay time
e
Feedback
Position
Pre, Post
Switches the feedback
connection p.473
f
Feedback –100...+100
Sets the feedback amount
p.473
High Damp
[%]
0...100
Sets the damping amount in
the high range
g
Input Level
Dmod [%]
–100...+100
Sets the modulation amount of
the input level p.472
Src Off...Tempo
Selects the modulation source
for the input level p.472
h
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Input Level
Input Level
+
High Damp
Delay
Feedback
Pitch Shifter
Feedback Position
Pre
Post
aMode
Slow,
Medium,
Fast
Switches Pitch Shifter mode
p.473
b
Pitch Shift
[1/2tone]
–24...+24
Sets the pitch shift amount in
steps of a semitone p.473
Src Off...Tempo
Selects the modulation source
of pitch shift amount p.473
Amt –24...+24
Sets the modulation amount of
pitch shift amount p.473
c
Fine [cents] –100...+100
Sets the pitch shift amount in
steps of one cent p.473
Amt –100...+100
Sets the modulation amount of
pitch shift amount p.473
d
BPM
MIDI,
40.00...
300.00
MIDI syncs to the system
tempo; 40–300 sets the tempo
manually for this individual
effect p.473
Time Over? ---, OVER!
Displays an error message
when the delay time exceeds
the upper limit p.473
e
Delay Base
Note
...
Selects the type of notes to
specify the delay time p.473
Times x1...x32
Sets the number of notes to
specify the delay time p.473
f
Feedback
Position
Pre, Post
Switches the feedback
connection p.473
g
Feedback –100...+100
Sets the feedback amount
p.473
High Damp
[%]
0...100
Sets the damping amount in
the high range
h
Input Level
Dmod [%]
–100...+100
Sets the modulation amount of
the input level p.472
Src Off...Tempo
Selects the modulation source
for the input level p.472
i
Wet/Dry
Dry, 1 : 99...
99 : 1, Wet
Sets the balance between the
effect and the dry input
Src Off...Tempo
Selects a modulation source for
Wet/Dry
Amt –100...+100
Sets the modulation amount
for Wet/Dry
BPM
BPM
Base Note x Times
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Input Level
Input Level
+
High Damp
Delay
Feedback
Pitch Shifter
Feedback Position
Pre
Post
Tempo
