9/29/09 System 824 Views 5-45
• Leq Reading
• SEL Reading
• Interval Duration
The Interval-a display is shown below for the LOG and
SSA instruments:
The following explains each of the display’s components:
Display label - This shows the current display (for example,
“Interval-a”).
Interval Number- The Interval display shows each
measurement interval in the order that it occurred. The
Interval Number indicates the order of the displayed interval
in relation to the other interval records.
Interval Date / Time - The Event Date/Time shows the time
and date that this interval began.
L
eq
Reading - The L
eq
Reading shows the Leq for the
currently displayed interval.
SEL Reading - The SEL Reading shows the SEL for the
currently displayed interval.
Display label
Interval Number
Interval Date/Time
Leq Reading
SEL Reading
Interval Duration
To Next Page
