11-4 824 Reference Manual 9/29/09

The menu layout of the RTA settings is shown in the table

below:

Menu Items Submenu Available Settings Options Available Settings Options

Title User customized text entry

RTA

Gain

(dB)

-20

-10

+10

+20

+30

+40

+50

Bandwidth

1/1

1/3

Detector

Lin

Exp

Lin Detc Time 0.0025 to 99.9975 sec

Exp Detc Time

(seconds)

1/32

1/16

1/8

1/4

1/2

Exp Store Rate

1/2 second

1/8 second

Transducer

Condnsr

Electret

Direct

Random Corr

Yes

Autostore

Yes

Pretrigger # 0-400 samples

Save ByTime

Yes

Trigger Setup

Triggering

Yes

Trigger Source

Any 1/1 or 1/3 octave filter

Flat
