9/29/09 A-27
Where “x” indicates a number to
represent a combination of
weighting and detector which has
these values:
If “x” is not provided or it is zero
then the value indicated by the Wght
and Detc settings is given.
NOTE: Impulse detector is not applica-
ble for Takt levels
Where “w” indicates a number to
represent the weighting which has
these values (Detector is not
applicable for these measurements):
1 A weight, Slow detector
2 A weight, Fast detector
3 A weight, Impl detector
4 C weight, Slow detector
5 C weight, Fast detector
6 C weight, Impl detector
7 Flat weight, Slow detector
8 Flat weight, Fast detector
9 Flat weight, Impl detector
1A weight
2C weight
3 Flat weight
