A-42 824 Reference Manual 9/29/09
S75 LOG EXCD EXCHANGE RATE
S75 RTA RTAf LOGIC OUTPUTS CONTROL
SETTING
(BIT MAPPED WORD: 3
OUTPUTS BY 5 STATES)
S76 LOG EXCD MINIMUM DURATION
S76 RTA RTAf END MODE [NEVER, L<, L=, L>,
INPUT, TIME, COUNT]
S77 LOG EXCD TIME-HIST ENABLE
S77 RTA RTAf END LEVEL (NNN.N) dB
S78 LOG EXCD TIME-HIST PERIOD
S78 RTA RTAf END TIME (SS.SSSS) SECONDS
S79 RTA RTAf END SAMPLES (NNNNN)
S80 LOG EXCD Passby Trigger Mode
S80 RTA RTAf END LOGIC INPUT TRUE
LEVEL
[LOW, HIGH]
S81 LOG EXCD Occurrence Time [Start | Max]
S81 RTA RTAf END THEN, REPEAT MODE [STOP, REPEAT, AVER-
AGE]
S82 LOG TIMED EXCD PERIOD MM:SS
S82 RTA RTAf REPEAT COUNT (NNN) O TO 255 TIMES
S83 SSA, LOG ENABLE INTV HISTORY
S83 RTA RTAf AVERAGE COUNT (N) 0 TO 9 TIMES
S84 SSA, LOG INTV EXCHANGE RATE
S84 RTA RTAf ANNUNCIATOR (CCCCCCCC) IF RIGHT
DIGIT IS NUMERIC IT
WILL AUTO-INCRE-
MENT
S85 SSA, LOG INTV THRESHOLD
To Next Page
