9/29/09 C-7
* Absolute maximum AC input voltage: 10Vpp
Permitted DC voltage range: - 3Vdc to + 30Vdc
Resolution
Levels: 0.1dB (0.01 dB via I/O)
Dose: 0.01%
Elapsed time: Highspeed RTA, as rapid as every 2.5 mS
all other instruments, 0.1 second
Real time clock 1 second
Calendar: 01 Jan 2000 - 31 Dec 2099
Cable Drive Capability (with PRM902 preamp)
Frequencies to 20 kHz: 700 feet 213 meters
Frequencies to 10 kHz: 1000 feet 305 meters
Maximum Input Voltage* (overload)
Gain VRMS Vpeak dBuV
0 dB 2.54 7.2 128
10 dB 0.74 2.1 118
20 dB 0.254 0.72 108
30 dB 0.080 0.227 98
40 dB 0.025 0.072 88
50 dB 0.008 0.023 78
