Larson Davis 824 - Page 557

9/29/09 C-11
.
RMS Measurement Range (LOG and ISM modes only)
Electrical
Noise Floor
Low
Limit
High
Limit
Range Pulse
Range
A-WT (high) < 22 < 43 151 > 108 > 108
A-WT (normal) < 12 < 23 131 > 108 > 108
A-WT (low) < 10 < 20 111 > 91 > 91
C-WT (high) < 38 < 48 151 > 103 > 103
C-WT (normal) < 18 < 28 131 > 103 > 103
C-WT (low) < 14 < 25 111 > 86 > 86
FLAT (high) < 40 < 50 151 > 101 > 101
FLAT (normal) < 20 < 30 131 > 101 > 101
FLAT (low) < 15 < 25 111 > 86 > 86
