Lenze i950

Parameter
Address Name / seng range / [default seng] Info
0x2822:021 Axis commands: Load default Lh saturaon character-
isc
Parameters for interacon with engineering tools.
0 O/Ready Obtain Hiperface informaon from the encoder for applicaon feedback.
1 On/Start
2 In process
3 Acon cancelled
4 No access
5 No access (controller inhibit)
0x2C07:001 Inductance grid points (y) Lh saturaon
characterisc:
y1 = L01 (x = 0.00 %)
0 ... [118] ... 400 %
Saturaon characterisc of the mutual inductance of an asynchronous
machine as a funcon of the magnesing current.
0x2C07:002 Inductance grid points (y) Lh saturaon characterisc:
y2 = L02 (x = 6.25 %)
0 ... [118] ... 400 %
0x2C07:003 Inductance grid points (y) Lh saturaon characterisc:
y3 = L03 (x = 12.50 %)
0 ... [118] ... 400 %
0x2C07:004 Inductance grid points (y) Lh saturaon characterisc:
y4 = L04 (x = 18.75 %)
0 ... [117] ... 400 %
0x2C07:005 Inductance grid points (y) Lh saturaon characterisc:
y5 = L05 (x = 25.00 %)
0 ... [116] ... 400 %
0x2C07:006 Inductance grid points (y) Lh saturaon characterisc:
y6 = L06 (x = 31.25 %)
0 ... [114] ... 400 %
0x2C07:007 Inductance grid points (y) Lh saturaon characterisc:
y7 = L07 (x = 37.50 %)
0 ... [111] ... 400 %
0x2C07:008 Inductance grid points (y) Lh saturaon characterisc:
y8 = L08 (x = 43.75 %)
0 ... [107] ... 400 %
0x2C07:009 Inductance grid points (y) Lh saturaon
characterisc:
y9 = L09 (x = 50.00 %)
0 ... [100] ... 400 %
0x2C07:010 Inductance grid points (y) Lh saturaon characterisc:
y10 = L10 (x = 56.25 %)
0 ... [93] ... 400 %
0x2C07:011 Inductance grid points (y) Lh saturaon characterisc:
y11 = L11 (x = 62.50 %)
0 ... [86] ... 400 %
0x2C07:012 Inductance grid points (y) Lh saturaon characterisc:
y12 = L12 (x = 68.75 %)
0 ... [78] ... 400 %
0x2C07:013 Inductance grid points (y) Lh saturaon characterisc:
y13 = L13 (x = 75.00 %)
0 ... [71] ... 400 %
0x2C07:014 Inductance grid points (y) Lh saturaon characterisc:
y14 = L14 (x = 81.25 %)
0 ... [64] ... 400 %
0x2C07:015 Inductance grid points (y) Lh saturaon characterisc:
y15 = L15 (x = 87.50 %)
0 ... [57] ... 400 %
0x2C07:016 Inductance grid points (y) Lh saturaon characterisc:
y16 = L16 (x = 93.75 %)
0 ... [50] ... 400 %
0x2C07:017 Inductance grid points (y) Lh saturaon
characterisc:
y17 = L17 (x = 100.00 %)
0 ... [42] ... 400 %
Conguring the motor control
Fine adjus
tment of the motor model
Asynchronous motor (ASM): Idenfy Lh saturaon characterisc
282
