Lenze i950

Parameter
Address Name / seng range / [default seng] Info
0x2C01:001 Motor parameters: Number of pole pairs
•
R
ead only
Display of the number of pole pairs calculated from the rated speed and
rated frequency.
0x2C01:002 Motor parameters: Stator resistance
0.0000 ... [13.5000] ... 125.0000 Ω
General motor data.
Carry out sengs as specied by manufacturer data/motor data sheet.
Note!
When you enter the motor nameplate data, take into account the phase
connecon implemented for the motor (star or delta connecon). Only
enter the data applying to the connecon type selected.
0x2C01:003 Motor parameters: Stator leakage inductance
0.000 ... [51.000] ... 500.000 mH
0x2C01:004 Motor parameters: Rated speed
0 ... [4050] ... 50000 rpm
General motor data.
Carry out sengs as specied by motor nameplate data.
Note!
When you enter the motor nameplate data, take into account the phase
connecon implemented for the motor (star or delta connecon). Only
enter the data applying to the connecon type selected.
0x2C01:005 Motor parameters: Rated frequency
0.0 ... [270.0] ... 1000.0 Hz
0x2C01:006 Motor parameters: Rated power
0.00 ... [0.25] ... 655.35 kW
0x2C01:007 Motor parameters: Rated voltage
0 ... [225] ... 65535 V
0x2C01:008 Motor parameters: Cosine phi
0.00 ... [0.80] ... 1.00
0x2C01:009 Motor parameters: Insulaon class Insulaon class of the motor (see motor nameplate).
0 Y (cut-o temperature = 90 °C)
1 A (cut-o temperature = 105 °C)
2 E (cut-o temperature = 120 °C)
3 B (cut-o temperature = 130 °C)
4 F (cut-o temperature = 155 °C)
5 H (cut-o temperature = 180 °C)
6 G (cut-o temperature > 180 °C)
0x2C02:001 Motor parameter (ASM): Rotor resistance
0.0000 ... [0.0000] ... 214748.3647 Ω
Equivalent circuit data required for the motor model of the asynchro-
nous machine.
0x2C02:002 Motor parameter (ASM): Mutual inductance
0.0 ... [0.0] ... 214748364.7 mH
0x2C02:003 Motor parameter (ASM): Magnesing current
0.00 ... [0.00] ... 500.00 A
0x2C03:001 Motor parameter (PSM): Back EMF constant
0.0 ... [41.8] ... 100000.0 V
/1000rpm
Voltage induced by the motor (rotor voltage / 1000 rpm).
For permanently excited synchronous motors, the e.m.f. constant
describes the r.m.s. value of the line-to-line voltage (phase voltage)
induced in idle state by the motor (reference: 1000 rpm, 20 °C).
0x2C03:002 Motor parameter (PSM): Resolver pole posion
-179.9 ... [-90.0] ... 179.9 °
Equivalent circuit data required for the motor model of the synchronous
machine.
0x2C03:003 Motor parameter (PSM): Magnets temperature coe-
cient (kTN)
-1.000 ... [-0.110] ... 0.000 %/°C
0x2C03:004 Motor parameter (PSM): Encoder pole posion
-179.9 ... [0.0] ... 179.9
°
0x2D4C:001 Thermisches Modell Motorauslastung (i²xt): Motor
ulisaon (i²xt)
1 ... [60] ... 36000 s
Seng of the me constant for the winding.
0x2D4C:002 Thermisches Modell Motorauslastung (i²xt): Thermal
me constant - laminaons
1 ... [852] ... 36000 s
Seng of the me constant for the laminated core.
0x2D4C:003 Thermisches Modell Motorauslastung (i²xt): Winding
inuence
0 ... [27] ... 100 %
Part of the thermal motor model: distribuon factor of the copper wind-
ing inuence.
Basic
seng
Motor data
Manual seng of the motor data
42
