3-40 Service Manual
5061
If you have an optional 2000-sheet drawer:
1. Open the 2000-sheet drawer access door. Pull the jam down and out of the rollers.
2. Close the door.
Area D
1.
Open the front access door.
2. Hold down the front access door. Remove jams in the rollers under the image transfer unit.
Note: Any image printed will not be fused to the page.
Area T1
1.
If clearing Area B did not clear the jam, then carefully open tray 1. Remove any jams.
Note: Make sure the paper is pushed all the way down into the tray.
2. Close tray 1.
To Next Page
