Lexmark C78x - Fuser Assembly Removal

4-44 Service Manual
5061
Fuser assembly removal
See “Fuser assembly” on page 7-7 for the part numbers.
1. Turn the printer off.
Note: The printer shouldbe powered down prior to removal and/or replacement of the fuser.
2. Open the lower right door assembly and redrive door.
CAUTION
Be sure the fuser assembly has cooled before you remove it.
