7-28 Service Manual
5061
Assembly 20: Cartridge contact assembly
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
20–1 40X1762 4 1 Cartridge contact assembly, complete
Also order cable tie parts packet (P/N 40X1648)
2 40X1636 4 1 Rear hold down spring
Also order cable tie parts packet (P/N 40X1648)
3 40X1760 4 1 Rear hold down bellcrank
Also order cable tie parts packet (P/N 40X1648)
1
2
3
