Parts catalog 7-1
5061
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
• Asm-index: identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and the item number 1.
• Part number: identifies the unique number that identifies this FRU.
• Units/mach: refers to the number of units actually used in the base machine or product.
• Units/option: refers to the number of units used in the option and does not include the base machine.
• Units/kit or pkg: refers to the number of units packaged together and identified by the part number.
• NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
• NA: (Not available) in the parts description column indicates the part is shown for identification purposes
only and is not available as a FRU.
The Lexmark C77x (506x-4xx) laser printer is available in four models:
Asm-
Index
Part
number
Units/mach
- OR -
Units/option
Units/
FRU
Description
Name
Machine
type/model
Description
Abbreviation used in
parts catalog
Lexmark C770 5061-110 Network 110
Lexmark C772 5061-310 Network 310
Lexmark C780n 5061-210 Network 210
Lexmark C782n 5061-410 Network 410
