3-44 Service Manual
5061
Clearing fuser jams
1.
Clear the paper path. If the jam error message persists, go to step 2.
2. Open both the upper right and the lower right access doors (Areas K and L).
3. Pull down the latches. They slide toward the center to release the fuser.
4. Pull the fuser out, and set it on a clean, flat surface.
5. Unsnap the housing, and set it aside.
CAUTION
The fuser assembly may be hot. Let it cool before continuing.
To Next Page
