Connector locations 5-17
5061
JR1
RIP fan
1 FAN3_STALL_IN
2 Ground
3 FAN3_CNTRL-
4 +24V_LEFTSIDE
5N/C
JTRAY1
Autocomp motor
1 +5 V dc Paper level (switched)
2 +5V_SWITCHED
3 PAPER_OUT_IN
4 AUTOCOMP_ENC
5 PAPER_LOW_IN
6 Ground
7 Ground
8 Ground
9 AUTOCOMP_OUT1 (+24 V dc in standby)
10 AUTOCOMP_OUT2 (+24 V dc in standby)
JUSB1
USB port
G1 Ground
1 USB +5 V dc
2 USB D-
3 USB D+
4 Ground
G2 Ground
JWEB1
Web oiler motor
1 +5 V dc (through fuse F8)
2 OILER_CURR_SEL_A
3 OILER_CURR_SEL_B
4 OILER_PHASE_A
5 OILER_PHASE_B
6 Ground
7 +24V_LEFTSIDE
JY1
VTB fan
1 FAN2_STALL_IN
2 Ground
3 VTB_FAN_OUT (Fan 2 control)
4 +24V_LEFTSIDE
J
INA Card Socket
See “System board” on page 5-7.
Connector Pin no. Signal
