Lexmark C78x User Manual

Connector locations 5-21
5061
Connector Pin no Signal
CN1 HVPS Input Connector 1 +24 V dc Switched
2 +24 V dc Return
3M-Txpwm
4M-Srvo out
5Y-Txpwm
6Y-Srvo out
7C-Txpwm
8C-Srvo out
9K-Txpwm
10 K-Srvo out
11 KCYM-Txenable
12 ITU-Txpwm
13 ITU-Srvo out
14 ITU-Txcurpwm
15 TUI-Txenable
T102 Transformer HV Terminal I
(ITU)
1 HV Transformer output to 2nd Transfer Roll Cable
T201 Transformer HV Terminal K
Black
1 HV Transformer Output Terminal to Black Transfer
Cable
T301 Transformer HV Terminal C
Cyan
1 HV Transformer Output Terminal to Cyan Transfer
Cable
T401 Transformer HV Terminal Y
Yellow
1 HV Transformer Output Terminal to Yellow Transfer
Cable
T501 Transformer HV Terminal M
Magenta
1 HV Transformer Output Terminal to Magenta
Transfer Cable
