Parts catalog 7-5
5061
Assembly 1.1: Covers
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
1.1–1 40X1657 1 1 Left upper cover assembly
2 21 1 Screw type 323, parts packet, (40X1633)
3 40X1653 1 1 Left upper pivot cover
4 40X1787 1 1 Jam access door spring
5 40X1658 1 1 Lower jam access door assembly
6 40X1655 1 1 Left lower pivot cover
7 40X1768 1 1 Reference edge nip release strap
8 40X1654 1 1 Left lower cover
9 40X1656 1 1 Waste container door
10 40X1647 1 1 Ground cable
11 40X1644 1 1 Rear cover
12 40X1643 2 2 Fuser latch slide
13 40X1645 2 2 Fuser latch slide spring
14 40X1640 1 1 Fuser top duct
15 40X1646 1 1 Duplex actuator arm assembly
16 40X1662 1 1 RIP fan duct
17 40X1642 1 1 Fuser wall duct
18 40X1641 1 1 Fuser bottom duct
19 40X1650 1 1 Fuser left duct
20 40X1652 1 1 Redrive belt cover duct
NS 40X1648 6 6 Cable tie (6 in pack)
Note: Use to secure cables to the inner system board shield)
NS 40X1649 2 2 Cable tie mount
NS 40X1671 6 6 Cable tie (6 in pack)
