Parts catalog 7-19
5061
Assembly 12: Multipurpose feeder (MPF)
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
12–1 40X1714 1 1 MPF door assembly—1xx/3xx
1 40X1841 1 1 MPF door assembly—2xx/4xx
2 40X1711 1 1 MPF door cover
3 40X1853 1 1 MPF drive assembly
4 40X1708 1 1 Door hinge restraint
5 12 12 Screw type 312/322/412/423, parts packet, 40X1691
6 40X1710 1 1 MPF gear cover
7 40X1673 1 1 MPF paper out flag
8 40X1852 1 1 Paper out sensor MPF
9 40X1715 2 2 MPF support bracket cover
10 40X1707 2 2 MPF support bracket spring
11 40X1717 2 1 MPF support bracket
12 40X1713 1 1 Frame bias latch cover
13 40X1712 1 1 Frame bias latch
14 40X1706 1 1 Frame bias spring
15 40X1716 1 1 MPF autocompensator pick assembly
16 40X1736 1 1 MPF side restraint
17 40X1682 1 1 MPF pick shaft
18 40X1709 1 1 MPF feed assembly—1xx/3xx
18 40X1840 1 1 MPF feed assembly—2xx/4xx
19 40X1808 1 1 Friction buckler and buckler housing
20 40X1704 5 5 Rib housing
NS 40X1854 1 1 MPF motor/sensor cable
