Lexmark C78x User Manual

Parts catalog 7-25
5061
Assembly 17: ITU loading
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
17–1 40X1761 1 1 Yellow terminal contact assembly
2 40X1744 4 1 Contact spring terminal
3 4 1 Screw type 312/322/412/423, parts packet, 40X1691
4 40X1743 8 1 Cartridge support roller
5 40X1749 1 1 Parts packet, ITU loading—yellow, including
- Yellow BOR spring
- Rear block guide
- Rear transfer bellcrank
- Front V block guide
- Front transfer bellcrank
- High voltage contact spring
6 40X1750 1 1 Parts packet, ITU loading—cyan, including
- Cyan BOR spring
- Rear V block guide
- Rear transfer bellcrank
- Front V block guide
- Front transfer bellcrank
- High voltage contact spring
7 40X1751 1 1 Parts packet, ITU loading (1xx/3xx)—magenta, including
- Magenta BOR spring
- Rear V block guide
- Rear transfer bellcrank
- Front V block guide
- Front transfer bellcrank
- High voltage contact spring
7 40X1849 1 1 Parts packet, ITU loading (2xx/4xx)—magenta, including
- Magenta BOR spring
- Rear V block guide
- Rear transfer bellcrank
- Front V block guide
- Front transfer bellcrank
- High voltage contact spring
8 40X1752 1 1 Parts packet, ITU loading—black, including
- Black BOR spring
- Rear block guide
- Rear transfer bellcrank
- Front V block guide
- Front transfer bellcrank
- High voltage contact spring
9 40X1753 1 1 Black terminal contact assembly
10 40X1757 1 1 Magenta terminal contact assembly
11 40X1759 1 1 Cyan terminal contact assembly
12 40X1747 1 1 BOR front cam
13 40X1748 1 1 BOR rear cam
14 40X1770 1 1 Front ITU guide
15 2 2 Screw type 323, parts packet, 40X1633
16 40X1745 1 1 ITU bias spring
17 40X1746 1 1 Rear ITU guide
