Parts catalog 7-37
5061
Assembly 23: Electronics—cabling interconnections 1
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
23–1 40X1637 1 1 Top autoconnect and output bin sensor—1xx/3xx only
1 40X1777 1 1 Top autoconnect and output bin sensor—2xx/4xx
2 40X1799 1 1 RIP fan, 92 mm
3 40X1758 1 1 Lift/BOR assembly
4 40X1807 1 1 Oiler motor driver cable
5 40X1801 1 1 Operator panel cable
6 40X1769 1 1 Operator panel USB cable
7 40X1828 1 1 Printhead assembly—yellow mirror motor (attached to yellow printhead)
8 40X1806 1 1 Laser cable—cyan/yellow
9 40X1828 1 1 Printhead assembly—cyan mirror motor (attached to cyan printhead)
10 40X1740 1 1 Printhead interlock cable assembly
11 40X1828 1 1 Printhead assembly—magenta mirror motor (attached to magenta
printhead)
12 40X1805 1 1 Laser cable—black/magenta
13 40X1828 1 1 Printhead assembly—black mirror motor (attached to black printhead)
14 40X1810 1 1 HVPS control cable—developer
15 40X1739 1 1 ITU light shield assembly
16 40X1692 1 1 S2/XPAR/NMS/MPF cable assembly (with sensors)
17 40X1854 1 1 MPF motor/sensor cable
18 40X1702 1 1 Registration motor assembly kit
19 40X1733 1 1 Pick motor extension and paper level sensing cable
20 40X1809 1 1 HVPS control cable—transfer
21 40X1804 1 1 ITU and black cartridge motor cable
22 40X1803 1 1 Cyan and magenta cartridge motor cable
23 40X1811 1 1 Options bottom/media size sensing cable assembly
24 40X1781 1 1 LVPS assembly
25 40X1800 1 1 VTB fan, 60 mm
26 40X1798 1 1 Fuser fan assembly
27 40X1802 1 1 Fuser and yellow cartridge motor cable
