Parts catalog 7-43
5061
Assembly 27: Output expander
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
27–1 40X1980 1 1 Output expander, complete
2 40X1997 1 1 ESD brush cover
3 40X1996 1 1 Right cover
4 40X1988 1 1 Deflector gate (also order 40X2000) Also called upper redrive deflecter.
5 40X2000 1 1 Upper diverter spring
6 40X2007 1 1 Exit shaft assembly, also order parts packet 40X2011
7 40X1999 1 1 Lower exit shaft assembly, also order parts packet 40X2011
8 40X1982 1 1 Output option card shield
9 40X2013 1 1 Output expander DC motor board
10 40X1984 1 1 Front control board cover
11 40X1992 1 1 Output expander tray
12 40X2014 1 1 Diverter arm
13 40X1978 1 1 Spring clutch assembly
14 40X2010 1 1 Output tray spring
15 2 1 Shaft bearing, parts packet, 40X2011
16 40X1991 1 1 Output tray latch
17 40X1981 2 1 Front attach bracket
18 40X2009 2 1 Swing arm spring
19 40X1995 1 1 Output expander assembly, mechanical linkage
20 40X1987 1 1 Rear support cover
21 40X1986 1 1 Rear cover
22 40X1989 1 1 Level sensor bracket
23 40X1990 1 1 Output paper level flag
24 40X3265 1 1 Dual bin full sensor
