Parts catalog 7-45
5061
Assembly 27.1: Output expander
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
27.1–1 40X1994 1 1 Right jam access door assembly
2 40X2006 1 1 Lower shaft assembly, also order parts packet 40X2011
3 40X2004 3 1 Drive pulley
4 40X1983 2 1 Rear attach bracket
5 4 4 Screw, parts packet, 40X1813
6 40X1985 1 1 Front cover
7 40X2002 1 1 160-gear belt
8 40X2003 1 1 Belt idler arm assembly
9 40X2005 1 1 Belt tensioner spring
10 40X2010 1 1 Output tray spring
11 40X1991 1 1 Output tray latch
12 40X2015 1 1 Frame assembly
13 40X3264 1 1 Output expander pass thru sensor
14 6 1 Shaft bearing, parts packet, 40X2011
15 40X2012 1 1 Shaft assembly, middle 40T, also order parts packet 40X2011
NS 40X1998 1 1 Multi-bin stacker kit
