Parts catalog 7-47
5061
Assembly 28: 5-Bin mailbox
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
28–1 40X2020 1 1 5-Bin mailbox, complete
2 40X2157 1 1 Access door rear latch
3 40X2049 10 1 Rear access door roller assembly
4 40X2024 1 1 Access door front latch
5 40X2032 1 1 Front door cover
6 40X4268 1 1 Front door assembly
7 40X2044 1 1 Left frame assembly w/clutch assembly
8 40X2056 1 1 Drive shaft bushing packet
9 40X2033 1 1 Right cover
10 40X2054 4 1 Drive shaft assembly
11 40X2055 1 1 Drive with gear shaft assembly
12 40X2029 1 1 Front cover
13 40X3242 5 1 5-bin mailbox pass thru sensor
14 40X2028 5 1 Paper cap tray
15 40X2043 1 1 5-bin mailbox assembly kit
16 40X2027 1 1 Bail attach bracket assembly
17 1 1 Bail, order P/N 40X2043, 5-bin mailbox assembly kit
18 40X2035 5 1 Paper tray support
19 40X2042 5 1 Paper tray stop assembly
20 40X2038 4 1 Bin full flag
21 40X2030 1 1 Rear structural cover
22 40X2023 5 1 Tray media level sensor cable
23 40X3240 5 1 Dual bin level sensor
24 40X2052 1 1 Lower autoconnect cable assembly
25 40X2050 1 1 Main DC drive assembly
26 40X2026 1 1 Bin full flag
27 40X2064 1 1 5-bin mailbox system board assembly
28 40X2067 1 1 Drive gear
29 40X2053 1 1 Upper autoconnect cable assembly
30 12 12 Screw, parts packet, 40X2046 (board mounting)
31 40X2031 1 1 Rear assembly cover
32 40X2000 1 1 Upper diverter spring
33 40X2025 1 1 Top bin cover
34 40X2040 1 1 Wire cover
35 40X1638 1 1 Redrive cap cover assembly
