Parts catalog 7-53
5061
Assembly 29.1: 500-Sheet drawer option
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
29.1–1 40X1901 1 1 Drive assembly, 500 option 2
2 31 31 Screw type 323, parts packet, 40X1633
3 40X1910 1 1 500-Sheet option tray pick assembly
4 40X1898 1 1 Paper level sensing assembly
5 40X1938 1 1 Autoconnect cable assembly
6 40X1648 1 6 Cable tie (6 in a pack)
Note: To secure cables to the inner system board shield)
7 40X1908 1 1 Frame cover
8 40X1730 1 1 Tray interlock bellcrank
9 40X1891 1 1 Pass thru sensor
10 40X1896 1 1 Hinge
11 40X1894 1 1 Electronics/size sensing assembly with system board
12 40X1741 1 1 Pick arm lift bellcrank
13 40X1899 1 1 Media size sensing assembly
14 40X1734 1 1 Bellcrank lift spring
15 40X1907 1 1 500-Sheet base assembly
16 40X1601 7 1 Machine pad
17 40X1903 1 1 Plate, 500-Sheet support assembly
18 40X1909 1 1 Paper guide
19 40X1897 1 1 Wall support plate
20 40X1911 1 1 Base door assembly
21 40X1895 1 1 500-sheet option spring
22 40X1913 1 1 500-Sheet option deflector
23 40X1765 2 2 Pick roll tires (2 per pack)
NS 40X1671 4 6 Cable tie (6 in pack)
