Lexmark C78x User Manual

Parts catalog 7-55
5061
Assembly 30: Duplex option
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
30–1 40X1920 1 1 Duplex option, complete
2 40X1961 1 1 Back cover
3 40X1965 5 1 Redrive bearing
4 40X1930 1 1 Duplex entry shaft assembly
5 20 20 Screw type 312/322/412/423, parts packet, 40X1691
6 40X1923 1 1 Right side front tray guide
7 40X1956 1 1 Deflector actuator assembly
8 40X1957 1 1 Deflector follower assembly
9 40X1959 1 1 Duplex front jam tray assembly
10 40X1935 1 1 Duplex support bracket
11 40X1964 1 1 Sensor mount plate
12 40X1927 1 1 Duplex exit sensor
13 40X1924 1 1 Duplex shaft mount
14 40X1954 1 1 Front decurl assembly
15 40X1979 1 1 F/R backup shaft assembly
16 40X1951 1 1 5 mm bushing
17 40X1948 1 1 Brake pad
18 40X1963 1 1 Duplex paper guide
19 40X1933 1 1 Wall support
20 40X1950 1 1 Brake spring
21 40X1947 1 1 Pass thru shaft assembly
22 40X1926 1 1 Duplex shaft assembly
23 40X1944 1 1 Pass thru spring
24 40X1814 1 1 Aligner arm spring
25 40X1942 1 1 Spur drive gear
26 40X1943 2 1 26T duplex gear
27 1 Retainer, parts packet, 40X1966
28 40X1946 1 1 Bellcrank assembly
29 40X1949 1 1 Decurl BAC assembly
30 40X1929 1 1 40T shaft drive F/R gear
NS 40X1955 1 1 Pulley washer
