Parts catalog 7-57
5061
Assembly 30.1: Duplex option
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
30.1–1 40X1934 1 1 Duplex support plate
2 40X1938 1 1 Autoconnect cable assembly
3 40X1939 1 1 DC forward/reverse motor assembly
4 40X1940 1 1 DC duplex feed motor
5 1 1 Screw type 323, parts packet, 40X1633
6 40X1648 6 6 Cable tie (6 in pack)
7 40X1937 1 1 Back support
8 40X1922 1 1 Duplex card assembly
9 40X1958 1 1 Transfer belt
10 40X1960 1 1 Right jam clearance tray assembly
11 40X1969 1 1 C-clip retainer
12 40X1953 2 1 Aligner spring
13 40X1967 2 1 Paper guide assembly
14 40X1941 2 1 Drive alignment shaft assembly
15 40X1952 1 1 Reduction gear shaft
16 40X1931 3 3 Right backup spring assembly
17 40X1968 2 1 Drive gear
18 40X1932 3 3 Left backup spring assembly
19 40X1962 1 1 Upper rib assembly
20 40X1925 1 1 Duplex input sensor
21 4 4 Screw type 324, parts packet 440X1635
